casting equipment

The casting production process is a complex and comprehensive combination of processes, which includes many production processes and links, from the preparation of metal materials and non-metal materials to alloy smelting, modeling, core making, mold pouring, cleaning, castings to eliminate defects and heat treatment, even to obtain qualified casting. The casting production process includes the following main processes:

1.Preparation of molding sand and core sand. The preparation process of molding sand directly affects the quality of molding sand. The preparation of molding sand is generally divided into raw material preparation and inspection, and molding sand preparation and quality control.

2.Modeling. The method and process of manufacturing sand molds with molding sand and patterns and other process equipment is called modeling. There are many types of modeling methods, which depend on the shape, size, and technical requirements of the casting.

3.Smelting.The process and operation of changing the metal from solid to liquid by heating and removing impurities in the molten metal through metallurgical reaction to make the temperature and composition meet the specified requirements is called smelting. There are many types of equipment for smelting metals,we produce cast iron platforms, and cupolas are generally used for machine tool castings.

4.Sand drying. Dry casting is generally used for some larger or high quality castings. For example, large cast iron platforms, machine tool bed castings, machine tool tables, machine tool castings, etc.

5.Pouring. The operation of pouring molten metal into the mold from the ladle is called pouring.

6.Cleaning. The process of removing the surface sticky sand, molding sand and excess metal from the casting after falling sand is called cleaning.

7.Casting heat treatment. The process of heating the casting to a certain temperature range, holding it for a period of time, and then cooling it to the appropriate temperature at a specified speed to obtain the expected structure and performance is called casting heat treatment. The purpose of heat treatment of the casting is to eliminate the casting stress of the casting. For example, cast iron platforms, machine tool castings, and machine tool tables must be processed after heat treatment.

So what casting equipment is needed to open a small sand casting plant? Here summarizes the equipment classification required for a sand casting plant: melting and pouring equipment, molding equipment, core making equipment, falling sand equipment, cleaning equipment, special casting six categories of equipment.

1.Melting and pouring equipment

(1)Cupola melting equipment mainly includes cupolas, blowers, batching equipment, and charging equipment, which are used for the batching, charging and melting of cast iron (gray iron, ductile iron). The melting and charging equipment of electric furnaces mainly include arc melting, induction furnaces, and resistance furnaces. Melting of various metal charge (steel, iron, aluminum).

(2) Pouring equipment mainly includes tilting pouring machine, pneumatic pouring machine, electromagnetic pouring machine, used for the pouring of molten metal.

2. Sand processing equipment

There are mainly sand mixers, loose sand machines, crushers, screening equipment, old sand reclaimers, drying equipment, old sand cooling equipment, magnetic separation equipment, used for the mixing and preparation of molding sand and core sand, and used sand Recycling, etc.

3.Modeling equipment

There are mainly vibration molding machines, compaction molding machines, vibration compaction molding machines, injection molding machines, air impact molding machines, static pressure molding machines, which are used for compaction and molding of molding sand and core sand.

4.Core making equipment

Mainly include hot core box core shooting machine, cold core box core shooting machine, shell core machine, used for the manufacture and forming of sand core shooter

5.Shaking equipment

There are mainly vibrating sand shaker, drum sand shaker, vibration conveying sand shaker, and wind driven sand shaker, which are used for sand shakeout and the separation of castings and molds (small foundries can manually pick out the castings with shovel! )

6.Cleaning equipment

Mainly include cleaning drum, shot blasting, shot blasting, combined shot and shot blasting, hydraulic sand cleaning equipment, electro-hydraulic sand cleaning equipment, used for surface cleaning of castings.

Above details for your reference, can be selected according to the factory's own production situation.
